Where is the superheater located in the boiler shown in the illustration? SG-0008

Correct Answer: Option D — G

Arrow G points directly to the interdeck superheater banks positioned between boiler generating tube banks where combustion gases provide the necessary thermal energy for steam temperature elevation per standard marine engineering layouts.
