Marine Electrical Systems USCG Question #936 (Set 32)

As shown in the illustration, if the port propulsion motor field excitation circuit experienced a failure, what individual component failure would allow the use of the standby excitation transformer and standby field controller to resume normal operation? EL-0164

USCG Exam Illustration EL-0164
USCG Examination Diagram: Illustration EL-0164
Official USCG Answer & Rule Citation

Correct Answer: Option C — port field controller

Under USCG National Maritime Center examination standards, the accepted correct answer is: port field controller.
